Balancer 10S BMS 20A Lithium Ion lifepo4 Batterie BMS pcm pcb mit Bluetooth und Communication

109,00  86,00

Intelligentes Batterie Management System (BMS)

zum Aufrüsten oder ersetzen im Elektroscooter oder sonstigen Batterie Packs.

Wahlweise mit Bluetooth Anbindung und/oder PC Communication.

Individuell einstellbare Parameter am PC oder per Android Handy.

Compare
Artikelnummer: 0004 Kategorien: , Schlüsselworte: , ,

Beschreibung

Mit PC Communication

Mit Bluetooth Anbindung

Mit Temperatur Sensor



Daten:

Function Test Project Test Condition Specification Unit
Min Middle Max
Over charge protection Over Charge Protection Voltage At charge off 4.22 4.25 4.28 V
Over Charge Protection Delay Time / 500 1000 1500 mS
Over Charge  Protection Release Voltage / 4.1 4.15 4.2 V
Balance Function Start Voltage / 3.57 3.6 3.63 V
Start Voltage difference / 30 mV
Balance current / 50 60 mA
Charge current Normal charge current / 60 A
Over charge current Over charge current / 65 70 75 A
Over charge current delay time / 2 5 8 S
Over charge current release / 15 S
Over temperature protection when charge High temperature protection / 62 65 68
High temperature charge release / 52 55 58
Low temperature charge protection / -12 -10 -7
Low temperature charge release / -3 0 3
Over discharge protection Over Disharge Protection Voltage At discharge off 2.42 2.5 2.58 V
Over Discharge Protection Delay Time / 500 1000 1500 mS
Over Charger  Protection Release Voltage / 2.7 2.8 2.9 V
Discharge current Max continuous current / 60 A
Over current Protection Over Current Protection 1 / 65 70 75 A
Over Current 1 Delay Time / 3 5 7 S
Over Current Release Over Current Release Condition / 32 S
Over current Protection Over Current Protection 2 / 80 90 A
Over Current 2 Delay Time / 100 320 500 mS
Over Current Release Condition / 32 S
Short Circuit Protection Short Circuit Protection / 150 200 250 A
Short Circuit Protection Delay Time / 200 400 800 uS
Short Circuit Release / Cut Off Load Delay Time 32S
Over temperature protection when Discharge High temperature protection / 67 70 73
High temperature discharge release / 57 60 63
Low temperature discharge protection / -12 -10 -7
Low temperature discharge release / -3 0 3
Internal Resistance Internal resistance of discharge circuit / 10 mR
Self-power consumption Normal Mode with Communication 20 mA
Sleeping Mode / 150 200 uA
Sleeping Delay Time / 8 10 S

Zusätzliche Information

Gewicht 02 kg
Bluetooth

Mit Bluetooth Anbind für Android Handys

ohne Bluetooth

Ohne Bluetooth Anbindung

mit PC Communication

mit PC Communication

mit PC und Bluetooth Communication

mit PC und Bluetooth Communication
